NikMann-2412 CNC Nesting Machine

Professional CNC nesting machine for cabinet makers, furniture manufacturers and joinery workshops. The NikMann-2412 combines accurate CNC routing, automatic tool changing, multi-spindle drilling and vacuum panel holding in one production-ready machine.

Listed Price $60,000 + GST
9.0 kW Italian HSD Spindle Precision CNC routing and cutting
12-Position Tool Changer Automatic tool changes for efficient production
10-Spindle Drilling Head Integrated drilling for cabinetry and furniture
Australia-Wide Support Installation, service and spare parts
NikMann-2412 CNC nesting machine for woodworking and cabinet making in Australia
NIKMANN-2412 CNC NESTING MACHINE

A Professional CNC Nesting Machine Built for Production

The NikMann-2412 is a three-axis CNC nesting machine designed for woodworking businesses that need accurate panel cutting, routing and drilling with an efficient, computer-controlled workflow.

Featuring a 9.0 kW Italian HSD electro spindle, a 12-position automatic tool magazine, a 10-spindle drilling head and a vacuum nesting table, the machine brings multiple panel-processing operations together in one production setup.

It is particularly suited to cabinet makers, furniture manufacturers, joinery workshops, shopfitters and other businesses producing cabinetry, furniture components and custom panel products.

Why upgrade to a CNC nesting machine?

Combining programmed cutting, routing and drilling in one machine can help reduce manual handling between operations, improve repeatability and streamline panel production.

The NikMann-2412 is designed for businesses looking to increase CNC capability, manage repeat production jobs and improve workflow efficiency with automatic tool changing and vacuum panel holding.

MACHINE FEATURES

NikMann-2412 Nesting CNC Machine Features

Professional CNC nesting machine for cabinet makers, furniture manufacturers and joinery workshops. The NikMann-2412 combines accurate CNC routing, automatic tool changing, multi-spindle drilling and vacuum panel holding in one production-ready machine.

software interface
01

SOFTWARE INTERFACE

Syntec controller works with absolute servo, so after switch on machine, you can run program directly, no need to home all axes.

Electrospindle & Drill Head
02

ELECTROSPINDLE & DRILL HEAD

Machine is equipped with Italian HSD-9kW Electro Spindle and 10 drills on a Drill Head.

Linear Tool Magazine
03

LINEAR TOOL MAGAZINE

Machine can maximize your productivity with 12-positions linear tool magazine travelling with the gantry. ISO-30 cone attachment.

Italian Made Electro Spindle
04

ELECTRO SPINDLE

Machine is equipped with Italian Made HSD 9kW / 24,000 rpm air cooled Electro Spindle type ISO-30.

Vacuum Table
05

VACUUM TABLE

Spline matrix table for locking of pieces of any shape. Versatility and flexibility, offering always the maximum possibilities of configuration.

Vacuum Pump
06

VACUUM PUMP

A powerful 5.5kw pump delivers 250 m3/h and delivers maximum vacuum evenly across the selected table area.

Automatic device for tool length measurement
07

AUTO MEASUMENT TOOL

Automatic device for tool length measurement for more precise cutting and drilling.

drill head
08

DRILL HEAD

Boring head for vertical boring operations with 10 independent mandrels to make short work of drilling, line boring and hinge hole machining.

automatic bearings lubrication
09

AUTO LUBRICATION

The bearings are automatically lubricated from a centralised lubrication system in X and Y.

remote control
10

REMOTE CONTROL

Magnetic hand control makes machine and tools setups simple and easy for the operator.

drill head configuration
11

DRILL HEAD CONFIGURATION

A powerful and versatile boring head with 10 drills, ideal for precise and efficient woodworking applications.

Iso-30 tools for electrospindle
12

ISO-30 TOOLS

This ISO-30 electro spindle is designed for high-precision machining and efficient tool changes, making it an excellent choice for CNC applications in woodworking and beyond.

automatic push off device
12

UNLOADING PUSHER

Auxiliary panels unloading unit allows the machined pieces to be taken off the working table that will then be cleaned by the suction device.

CNC NESTING & PANEL PROCESSING

From Sheet Material to Finished Components

The NikMann-2412 combines CNC routing, cutting and drilling in a coordinated workflow designed for professional woodworking production.

01 / PREPARE

Panel Loading & Vacuum Holding

Position the sheet material on the nesting table and use the vacuum system to help secure the panel during machining.

02 / PROGRAM

CNC Job Setup

Load compatible CAD/CAM programs and configure the required cutting paths, routing operations and drilling tasks.

03 / MACHINE

Routing, Cutting & Drilling

The 9.0 kW HSD electro spindle, automatic tool changer and 10-spindle drilling head support programmed panel-processing operations.

04 / COMPLETE

Unload & Prepare for Production

Remove the machined components, check them against job requirements and prepare the nesting table for the next production cycle.

MACHINE CONFIGURATION

NikMann-2412 CNC Nesting Machine Technical Specifications

The NikMann-2412 combines CNC routing, automatic tool changing and multi-spindle drilling for professional panel processing. Specifications are based on the published machine configuration. Contact Forza Machinery to confirm the current specification and available options.

MachineNikMann-2412
Machine TypeThree-Axis CNC Nesting Machine
ApplicationPanel Cutting, CNC Routing and Drilling
Cutting Capacity2420 × 1220 mm
Table Size2440 × 1220 mm
X-Y-Z Travel Speed60 / 60 / 20 m/min
Electro SpindleItalian HSD, ISO-30
Spindle Power9.0 kW
Maximum Spindle Speed24,000 rpm
Spindle CoolingAir Cooled
Automatic Tool Changer12-Position Linear Tool Magazine
Drilling Head10 Spindles
Vacuum TableDouble-Layer PVC Nesting Table
Vacuum Pump250 m³/h (published capacity)
CNC Control SystemSyntec
Servo Motors and DriversSyntec, 1 kW published configuration
Inverter11 kW
TransmissionHelical Rack and Pinion with Planetary Reducer
Lubrication SystemAutomatic Linear-Rail Lubrication
Tool Measuring SensorIncluded in Published Configuration
Safety EquipmentSafety Fence and Light Curtains
Additional EquipmentAuto Tool Sensor and Push-Off Device
Machine Dimensions4000 × 2300 mm (published)
Price$60,000 + GST

Delivery, installation and operator training are excluded from the listed price. Confirm the final machine configuration, dimensions, electrical and extraction requirements, availability and pricing with Forza Machinery before ordering.

APPLICATIONS

Who Is the NikMann-2412 Designed For?

A production-focused CNC nesting machine for businesses requiring accurate panel cutting, routing and drilling.

Cabinet Makers

Suitable for processing kitchen, wardrobe, bathroom and custom cabinetry components with programmed cutting and drilling operations.

Furniture Manufacturers

CNC routing, cutting and drilling for suitable furniture panels and components, supporting repeatable production workflows.

Joinery Workshops

Designed for workshops looking to integrate multiple panel-processing operations into one CNC machine.

Shopfitters

Suitable for machining components for commercial cabinetry, counters, display units and interior fit-out projects.

Production Workshops

A practical solution for businesses seeking automatic tool changing, multi-spindle drilling and efficient CNC panel processing.

Panel Furniture Manufacturers

Designed for nesting and machining suitable MDF, particleboard, plywood and other compatible sheet materials, subject to tooling and machine setup.

WHY NIKMANN-2412

More CNC Capability. Greater Consistency. Efficient Panel Processing.

The NikMann-2412 combines CNC routing, automatic tool changing and multi-spindle drilling to help woodworking businesses streamline panel production and reduce repetitive manual operations.

✓

Automatic Tool Changing

The 12-position linear tool magazine supports automatic tool changes during compatible programmed jobs, reducing the need for manual tool changes.

✓

Integrated Drilling

The 10-spindle drilling head supports drilling operations commonly required for cabinetry, furniture and other panel-based products.

✓

Vacuum Nesting Table

The double-layer PVC nesting table and vacuum holding system help secure suitable sheet materials during CNC machining.

✓

Production Efficiency

Combining routing, cutting and drilling in one CNC workflow can reduce handling between operations and support repeatable production.

Forza Machinery woodworking CNC machinery sales and support
SALES • INSTALLATION • SERVICE

Your NikMann-2412 Is Supported by Forza Machinery

Choosing a CNC nesting machine is an important investment in your workshop. Forza Machinery helps Australian woodworking businesses assess their machining requirements and organise the support needed to integrate new machinery into production.

  • Machine selection and application advice
  • Production requirements assessment
  • Delivery coordination
  • Installation and commissioning arrangements
  • Operator training
  • Preventive maintenance
  • CNC machinery servicing and repairs
  • Technical support
  • Spare parts assistance
COMPARE NIKMANN CNC MACHINES

Is the NikMann-2412 the Right CNC Machine for You?

Compare the NikMann-2412 with other CNC nesting machines and routing solutions to find the right configuration for your workshop, materials and production requirements.

If the NikMann-2412 CNC Nesting Machine is not the ideal fit for your business, Forza Machinery can help you explore alternative CNC machines based on working capacity, spindle requirements, automatic tool changing, drilling capability and production volume.

Industrial CNC woodworking router
CNC ROUTER

CNC Routing Machines

Explore CNC routing solutions for accurate cutting, profiling, engraving and machining of suitable wood-based materials.

View CNC Routers →
NikMann-3618k CNC nesting machine with automatic tool changing
CNC NESTING

NikMann-3618

A three-axis CNC nesting machine featuring a 9.0 kW HSD spindle, 12-position automatic tool magazine and 10-spindle drilling head.

View NikMann-3618k →
CNC woodworking machinery for professional panel processing
CNC MACHINERY

Explore CNC Solutions

Discuss your panel sizes, machining operations, software requirements and production goals with Forza Machinery to identify a suitable CNC configuration.

Explore CNC Machines →
NIKMANN-2412 FAQ

Frequently Asked Questions

Answers to common questions about the NikMann-2412 CNC nesting machine for woodworking, cabinet making and furniture production.

What is the NikMann-2412 CNC nesting machine?
The NikMann-2412 is a three-axis CNC nesting machine designed for panel cutting, routing and drilling in professional woodworking workshops, including cabinetry, joinery and furniture manufacturing.
What is the cutting capacity of the NikMann-2412?
The published cutting capacity is 2420 × 1220 mm, with a listed table size of 2440 × 1220 mm. Confirm the usable working area with Forza Machinery before ordering.
What spindle is fitted to the NikMann-2412?
The published configuration includes a 9.0 kW Italian HSD ISO-30 air-cooled electro spindle with a maximum speed of 24,000 rpm.
Does the NikMann-2412 have an automatic tool changer?
Yes. The listed configuration includes a 12-position linear tool magazine that supports automatic tool changes during compatible programmed machining jobs.
Does the NikMann-2412 include a drilling head?
Yes. The published configuration includes a 10-spindle drilling head for drilling operations commonly used in cabinetry and furniture manufacturing. Confirm your specific drilling requirements with Forza Machinery.
What control system does the NikMann-2412 use?
The published configuration specifies a Syntec CNC control system with Syntec servo motors and drivers. Confirm CAD/CAM software compatibility and post-processor requirements before ordering.
What materials can the NikMann-2412 process?
The machine is designed for suitable sheet materials used in cabinetry, furniture and joinery, including MDF, particleboard and plywood. Material thickness, tooling and machining results depend on the specific application and machine setup.
How much does the NikMann-2412 cost in Australia?
The listed price is $60,000 + GST. Delivery, installation and operator training are excluded. Contact Forza Machinery to confirm current pricing, availability and configuration options.
Does Forza Machinery provide installation and support?
Forza Machinery can discuss delivery, installation, commissioning, operator training, technical support, servicing and spare parts assistance. Confirm the services included in your quote before ordering.

Looking for a CNC Nesting Machine for Your Workshop?

Talk to Forza Machinery about the NikMann-2412 and find out whether its cutting capacity, spindle, drilling head and tool-changing configuration suit your production needs.
